Filter media

Filter media

Subcategories

  • Cut-to-size coarse...

    Cut-to-size coarse dust filter mats made of synthetic mediaFilter classes G2 - G4

    SF coarse dust filter mats are used as preliminary filters where heavy dust loads are encountered in air-conditioning systems and in the intake air of painting and drying systems. The filter medium has a progressive depth structure that increases towards the clean-air side. SF coarse dust filter mats are made of break-resistant synthetic fibres that are fee of substances that can damage paint (silicone-free).

    Material properties:

    Filter medium tested in acc. with EN 779
    Fire protection in acc. with DIN 53438 (F1)
    Moisture resistance up to 100% rel. hum.
    Temperature-resistant up to maximum 80°C
    SF designation SF-FL100 SF- FL150 SF- FL200 SF- FL220 SF- V15/350 SF- V15/400
    Filter class in acc. with EN 779 G2 G2 G3 G4 G4 G4
    Mean filtration efficiency 65% - 80% 65% - 80% 80% - 90% =90% =90% =90%
    Material thickness (approx.) 5 mm 11 mm 22 mm 24 mm 19 mm 20 mm
    Surface weight (approx.) 100 g/m² 150 g/m² 200 g/m² 220 g/m² 280 g/m² 350 g/m²
    Initial pressure drop* 20 Pa 25 Pa 35 Pa 35 Pa 50 Pa 60 Pa
    Recommended final pressure drop 250 Pa 250 Pa 250 Pa 250 Pa 250 Pa 250 Pa
    Flow velocity 1,5 m/s 1,5 m/s 1,5 m/s 1,5 m/s 1,5 m/s 1,5 m/s
    *checked against plan
  • Cut-to-size fine dust...

    Cut-to-size fine dust filter mats made of synthetic media Filter classes M5 - M6

    SF fine dust filter mats are used in the intake air in industrial painting systems (SF-V300S and SF-V400S) and in painting and paint spraying systems (SF-V500S, SF-V600G and SF-V5micron). The filter medium has a progressive depth structure that increases towards the clean-air side. SF fine dust filter mats are free of substances that can damage paint (silicone-free). SF-V500S, SF-V600G and SF-V5micron are impregnated with a dust binding agent, and a polyester fabric on the clean-air side further increases the stability of our SF-V600G und SF-V5micron.

    Material properties:

    Filter medium tested in acc. with EN 779
    Fire protection in acc. with DIN 53438 (F1)
    Moisture resistance up to 100% rel. hum.
    Temperature-resistant up to maximum 80°C
    SF designation SF- V300S SF- V400S SF- V500S SF- V600G SF-V5 MIC
    Filter classes in acc. with EN 779 M5 M5 M5 M5 M6
    Mean efficiency at 0.4 µm (%) 40% - 60% 40% - 60% 40% - 60% 40% - 60% 60% - 80%
    Material thickness (approx.) 15 mm 20 mm 25 mm 25 mm 25 mm
    Surface weight (approx.) 300 g/m² 400 g/m² 550 g/m² 650 g/m² 750 g/m²
    Initial pressure drop* 15 Pa 20 Pa 25 Pa 30 Pa 35 Pa
    Recommended final pressure drop 450 Pa 450 Pa 450 Pa 450 Pa 450 Pa
    Nominal volumetric flow(m³/h/m²) 900 900 900 900 900
    Flow velocity 0,25 m/s 0,25 m/s 0,25 m/s 0,25 m/s 0,25 m/s
    *checked against plan
  • Coarse dust filter mat...

    Coarse dust filter mat rolls made of synthetic media Filterclasses G2 - G4

    SF coarse dust filter mats are used as preliminary filters where heavy dust loads are encountered in air-conditioning systems and in the intake air of painting and drying systems. The filter medium has a progressive depth structure that increases towards the clean-air side. SF coarse dust filter mats are made of break-resistant synthetic fibres that are fee of substances that can damage paint (silicone-free).

    Material properties:

    Filter medium tested in acc. with EN 779
    Fire protection in acc. with DIN 53438 (F1)
    Moisture resistance up to 100% rel. hum.
    Temperature-resistant up to maximum 80°C
    SF designation SFMR-
    FL100
    SFMR-
    FL150
    SFMR-
    FL200
    SFMR-
    FL220
    SFMR-
    V15/350
    SFMR-
    V15/400
    Filter class in acc. with EN 779 G2 G2 G3 G4 G4 G4
    Mean filtration efficiency 65% - 80% 65% - 80% 80% - 90% =90% =90% =90%
    Material thickness (approx.) 5 mm 11 mm 22 mm 24 mm 19 mm 20 mm
    Surface weight (approx.) 100 g/m² 150 g/m² 200 g/m² 220 g/m² 280 g/m² 350 g/m²
    Initial pressure drop* 20 Pa 25 Pa 35 Pa 35 Pa 50 Pa 60 Pa
    Recommended final pressure drop 250 Pa 250 Pa 250 Pa 250 Pa 250 Pa 250 Pa
    Roll length 40 m 40 m 20 m 20 m 20 m 20 m
    Flow velocity 1,5 m/s 1,5 m/s 1,5 m/s 1,5 m/s 1,5 m/s 1,5 m/s
  • Fine dust filter mat...

    Fine dust filter mat rolls made of synthetic media Filter classes M5 - M6

    SF fine dust filter mats are used in the intake air in industrial painting systems (SFMR-V300S and SFMR-V400S) and in painting and paint spraying systems (SFMR-V500S, SFMR-V600G and SFMR-V5micron). The filter medium has a progressive depth structure that increases towards the clean-air side. SF fine dust filter mats are free of substances that can damage paint (silicone-free). SFMR-V500S, SFMR-V600G and SF-V5micron are impregnated with a dust binding agent, and a polyester fabric on the clean-air side further increases the stability of our SFMR-V600G and SFMR-V5micron.

    Material properties:

    Filter medium tested in acc. with EN 779
    Fire protection in acc. with DIN 53438 (F1)
    Moisture resistance up to 100% rel. hum.
    Temperature-resistant up to maximum 80°C

    SF designation SFMR-
    V300S
    SFMR-
    V400S
    SFMR-
    V500S
    SFMR-
    V600G
    SFMR-V5 MIC
    Filter classes in acc. with EN 779 M5 M5 M5 M5 M6
    Mean efficiency at 0.4 µm (%) 40% - 60% 40% - 60% 40% - 60% 40% - 60% 60% - 80%
    Material thickness (approx.) 15 mm 20 mm 25 mm 25 mm 25 mm
    Surface weight (approx.) 300 g/m² 400 g/m² 550 g/m² 650 g/m² 750 g/m²
    Initial pressure drop* 15 Pa 20 Pa 25 Pa 30 Pa 35 Pa
    Recommended final pressure drop 450 Pa 450 Pa 450 Pa 450 Pa 450 Pa
    Roll length 20 m 20 m 20 m 20 m 20 m
    Nominal volumetric flow (m³/h/m²) 900 900 900 900 900
    Flow velocity 0,25 m/s 0,25 m/s 0,25 m/s 0,25 m/s 0,25 m/s
    *checked against plan
  • Cut-to-size fibreglass...

    Cut-to-size fibreglass filter mats Filter classes G2 - G4

    SF fibreglass filter mats Paint-Stop (green) are designed especially for separating out paint mist in the exhaust air of painting systems and paint spraying stands. The dusty air side is coloured green. Paint-Stop (green) is free of substances that can damage paint (silicone-free). SF fibreglass filter mats Dust-Stop (yellow) are for separating out dry dust. The dusty air side is coloured yellow. Dust-Stop (yellow) has an antibacterial dust binding agent (silicone-free).
    SF designation SF- PAINT2" SF- PAINT3" SF- PAINT4" SF- DUST1" SF- DUST2" SF- DUST4"
    Filter class* - - - G2 G3 G4
    Filtration efficiency** 94% 96% 98% - - -
    Nominal volumetric flow (m³/h/m²) 2500-6300 2500-6300 2500-6300 9000-10800 9000-10800 9000-10800
    Material thickness (approx.) 50 mm 70 mm 100 mm 25 mm 50 mm 100 mm
    Temperature resistance (max.) 180°C 180°C 180°C 80°C 80°C 80°C
    *tested in acc. with EN 779

    **The filtration efficiency is dependent on the paint type, the mist and the ambient conditions such as the temperature or pressure in the booth.
  • Fibreglass filter mat...

    Fibreglass filter mat rolls Filter classes G2 - G4

    SF fibreglass filter mats Paint-Stop (green) are designed especially for separating out paint mist in the exhaust air of painting systems and paint spraying stands. The dusty air side is coloured green. Paint-Stop (green) is free of substances that can damage paint (silicone-free).
    SF fibreglass filter mats Dust-Stop (yellow) are for separating out dry dust. The dusty air side is coloured yellow. Dust-Stop (yellow) has an antibacterial dust binding agent (silicone-free). The standard roll length is 20 metres, other roll length on enquiry.
    SF designation SFMR- PAINT2" SFMR- PAINT3" SFMR- PAINT4" SFMR- DUST1" SFMR- DUST2" SFMR- DUST4"
    Filter class* - - - G2 G3 G4
    Filtration efficiency** 94% 96% 98% - - -
    Nominal vol. flow (m³/h/m²) 2500-6300 2500-6300 2500-6300 9000-10800 9000-10800 9000-10800
    Material thickness (approx.) 50 mm 70 mm 100 mm 25 mm 50 mm 100 mm
    Roll length 20 m 20 m 20 m 20 m 20 m 20 m180°C
    Temperature resistance (max.) 180°C 180°C 180°C 80°C 80°C 80°C
    *tested in acc. with EN 779

    **The filtration efficiency is dependent on the paint type, the mist and the ambient conditions such as the temperature or pressure in the booth.
  • Rubberised hair filter...

    Rubberised hair filter elements consist of latex-bonded, randomly distributed natural mixed fibres that possess high inherent rigidity. The filter elements are regenerable and are used where high dust concentrations and coarse dusts must be separated out. (e.g. compressors and ventilation zones in the cement industry)

  • Filter foams PPI PPI...

    Filter foams PPI PPI 10 - PPI 90

    Filter foams are made from polyurethane ester or polyurethane ether. Polyurethane ether foams are used in water filtration. They are resistant to salt water. Polyurethane ester foams are used in air filtration. They are resistant to ozone and oxygen. Filter foams have a homogeneous number of pores. The pore size is between 10 ppi and 90 ppi (ppi = pores per inch).

    Send us an enquiry for your filter foam, with details of the use, the PPI and the mass.
